Leírás
Features:
– Brand new and high quality
– Made of high quality materials, durable
– Excessive current can cause increased heating of the bimetal, which can cause the contacts to open, shutting down the device
– Usage Electric motors, water pumps, electric drills, cutting machines, power tools, mechanical hardware, etc.
– Disconnection time :
– 100 rated current: no disconnect
– 150% rated current: disconnected in about 1 hour
– 200% rated current: 5-25 seconds disconnect
– 300% rated current: 1.5-5 seconds disconnect
Specification:
– Body size: 35mmx14.5mmx42.5mm
– Hole size 10.5mm
– Thread: 10mm.
– Name overload protector
– Rated voltage AC 125/250V DC 32V
– Rated current 5A10A15A 20A (optional)
– Reset method Manual reset
– Material: plastic case/bakelite case/copper contacts/compound silver
Package Included:
1 * Overload protector (optional)
Notes:
1. Due to various factors such as display brightness and light brightness, the actual color of the product may be slightly different from the website picture.
2. Please allow a slight deviation between the data and the manual measurement.
