Leírás
T-Display ESP32 WiFi és Bluetooth modulfejlesztő kártya 1,14 hüvelykes LCD-hez
T-Display ESP32 WiFi And Bluetooth Module Development Board For 1.14 Inch LCD
Product Description
Hardware Specifications
Chipset ESPRESSIF-ESP32 240MHz Xtensa® single-/dual-core 32-bit LX6 microprocessor
FLASH QSPI flash 4MB
SRAM 520 kB SRAM
Button Reset
USB to TTL CP2104
Modular interface UART.SPI.SDIO.I2C.LED PWM.TV PWM.I2S.IRGPIO.ADC.capacitor touch sensor.DACLNA pre-amplifier
Display IPS ST7789V 1.14 Inch
Working voltage 2.7V-4.2V
Working current About 67MA
Sleep current About 350uA
Working temperature range -40 ~ 85
Size&Weight 51.52*25.04*8.54mm(7.81g)
Power Supply Specifications
Power Supply USB 5V/1A
Charging current 500mA
Battery 3.7V lithium battery
JST Connector 2Pin 1.25mm
USB Type-C
