Two speed modes: high-speed mode and low-speed mode. The parameters of high-speed mode are expressed as follows: (SP-H,) smoothing filtering, and (SP-L) no smoothing filtering and cryptographic protection.
Shape size: 48 * 96 * 75MM (width * length * depth), opening size: 45 * 92MM (width * length).
ZNZS-6E2RB upper and lower limit alarm output, two sets of relay alarm output, other functions are the same as ZNZS-6E1R.
In order to meet the needs of users, our company has introduced the speed meter of DC24V power supply. The original function of the speed meter remains unchanged. If DC24V power supply and customer service are needed, we default to send the speed meter of 220V power supply.
ZNZS-6E1R-M485, with 485 communication port, has pulse equivalent setting, stop alarm output, motion on-line alarm output (measurement value is greater than set value), a group of relay alarm output.
There are two kinds of MODBUS protocol: standard and non-standard. Customers can choose according to their needs. It can communicate with computers, text, touch screens. It can display speed/linear speed, the lowest can display 0.1 rpm, the highest can display 100000 rpm. At this time, the selected sensors are different.
A set of relay output (OUT1 output)
Speed range (6 bits) – 99999-999999
Computable (Pulse Equivalent: 0.001-9999, see Point 7 of Usage Method)
Can be set as tachometer (n/min) and linear tachometer (mm/s)
Locable decimal point
