Leírás
EKG/EKG/EMG Shield Arduino-hoz kábelekkel és elektródákkal
ECG/EKG/EMG Shield for Arduino with Cables and Electrodes
FEATURES
Stackable headers up to 6 channels may be stacked and wired to A0-A6 analogue inputs
Calibration signal generation by D4/D9 digital output
Precise Trimmer potentiometer for calibration (all boards are shipped completely assembled, tested and calibrated so that you don’t have to do this unless you want to see how things works)
Input connector for normal or Active electrodes
Works with both 3.3V and 5V for boards
DOCUMENTS
SHIELD-EKG-EMG user's manual revision E
HARDWARE
SHIELD-EKG-EMG schematic in PDF format released under Creative Commons Attribution-Share Alike 3.0 United States License
SHIELD-EKG-EMG schematic and board in Eagle format released under Creative Commons Attribution-Share Alike 3.0 United States License
