Leírás
Az SHTC3 nagy pontosságú digitális hőmérséklet- és páratartalom-érzékelő I2C modulja kommunikációja jobb, mint az AM2302 DHT22
SHTC3 High Precision Digital Temperature and Humidity Sensor Measurement Module I2C Communication is Better than AM2302 DHT22
Pin description
1. VDD Power Supply 3.3-5.5V DC
2. GND grounding, power supply negative pole
3. SDA Serial Data, Two-way Port
4. SCL Serial Clock, Input Port
Technical parameters:
1. Measurement range of humidity:0~100% RH
2. Precision of humidity measurement: ±2% RH
3. Temperature Measurement Range: -40~125°
4. Accuracy of temperature measurement: ±0.2°
5. Working Voltage: 3.3~5VDC
6. I2C Interface Output
Applications:
HVAC, dehumidifier, agriculture, cold chain storage, testing and testing equipment, consumer goods, automobiles, automatic control, data recorder, weather station, household appliances, humidity regulator, medical treatment, and other related humidity detection and control.
