Product Name:
1PCS Red Mini LED Board for Arduino UNO MEGA2560 Nano Breadboard starter kit
Packing list:
1 pcs Red 6 bit LED’s Board,
Description:
Can be inserted directly into Arduino uno mega2560,Ideal for linking up to your Arduino UNO Mini Nano Mega2560 etc,or others MCU ( AVR STM32 ARM PIC AT89C51 STC MSP430 FPGA CPLD etc.)
1 6 bit RED Common Cathode LEDS.
2 7 PIN OUT 2.54mm
3 1K ohm Limiting resistor
4 Power Supply Voltage: 3.3-12V,
5 Size: 17.78MM x 11.43MM.
PCB :
Circuit schematics :
Connection with Arduino(Only 6 bit LED’s Board ,Does not include ARDUINO UNO R3)
Brand:Eletechsup
Moduct Name : 4 Button Key Module Switch Keyboard for Arduino UNO MEGA2560 Breadboard
Module No.: TB371
Description:
Key pad for FPGA CPLD Altera EP4EC6 EPM240 EPM570 Xilinx XC6SLX9 development kit
Can be inserted directly into Arduino uno mega2560,Ideal for linking up to your Arduino UNO Mini Nano Mega2560 Breadboard etc,or others MCU ( AVR STM32 ARM PIC AT89C51 STC MSP430 STM8 FPGA CPLD etc.)
1 4-button Common Cathode key module .
2 ” GND K1 K2 K3 K4” 4 PIN OUT 2.54mm
3 Size: 12.7MM x 33MM.
Specifications
Material
Composite materials
Origin
Mainland China
6 bit LED key
Red
is_customized
Yes
Operating Temperature
-35-80 Degrees Celsius
Dissipation Power
10-20MW
Supply Voltage
3-12V
Condition
New
Type
led button
Application
MCU Development Board
