Leírás
Model 2510
Voltage DC 5V
Rated current 0.06A
Size 25*25*10MM
Power consumption 0.3W
Speed 7000±10%RPM
Noise 20.3DBA
Weight7.5 grams
Life 40000 hours at 40?
Bearing structure :Hydraulic sealed bearing
Wiring mode :Red wire positive and black wire negative
Temperature range: -10 +75?
Storage humidity 5 T0 95% RH
Model 2510
Voltage DC 12V
Rated current 0.04A
Size 25*25*10MM
Air volume 1.7CFM
Power consumption 0.48W
Speed 8762±10%RPM
Noise 22.8DBA
Weight7.5 grams
Life 40000 hours at 40?
Bearing structure :Hydraulic sealed bearing
Wiring mode :Red wire positive and black wire negative
Temperature range: -10 +75?
Storage humidity 5 T0 95% RH
Model 2510
Voltage DC 9V
Rated current 0.07A
Size 25*25*10MM
Air volume 2.3CFM
Power consumption 0.63W
Speed 11895±10%RPM
Noise 25.5DBA
Weight7.5 grams
Life 40000 hours at 40?
Bearing structure :Hydraulic sealed bearing
Wiring mode :Red wire positive and black wire negative
Temperature range: -10 +75?
Storage humidity 5 T0 95% RH
Model 2510
Voltage DC 24V
Rated current 0.04A
Size 25*25*10MM
Air volume 2.5CFM
Power consumption 0.96W
Speed 12678±10%RPM
Noise 25.6DBA
Weight7.5 grams
Life 40000 hours at 40?
Bearing structure :Hydraulic sealed bearing
Wiring mode :Red wire positive and black wire negative
Temperature range: -10 +75?
Storage humidity 5 T0 95% RH
